mglondonroadste. If your brake master IS mounted to the VW frame head (Napolean’s Hat) you need to disconnect the MC bolts from the inside but DO NOT pull them out all the way. The frame head piece is double-walled with a spacer sleeve over the bolts between the walls (to prevent buckling should the bolts be over torqued.) If you pull the MC…[Read more]

The sure way to find it is to start at the driver’s side from wheel and trace the brake line until you get to the thing with all the other brake lines coming out of it. There will be two bolts fastening it to a bulkhead. In a VW pan that would be the “Napolean’s Hat” cross member just behind the front wheels. I think your chassis is custom but…[Read more]

No one?

@pmossberg only if it’s a custom part that’s already designed. That was the difficult part. The printing itself was easy!

@kms1 you can actually buy one for just around $250 these days that will print good enough quality for most things.

I’ve since designed and printed some “reducer” adapters so that my under-seat heater vents properly connect…[Read more]

Hey Kall, et. al. — really good point on rotating the electrical panel 180 degrees so that the terminal strip and wires will not interfere with changing the fuses….

…I made some changes to the layout and will post pics under my Ford TDr build post — (don’t want to hijack the “refresh Sammy” post ……)

Thanks,

Happy Jack

Hey Ric, if you really want a low oil press light, you can install a T in the line and have both a pressure gauge and a light.  The “sending unit” for the light is simply a pressure switch that is closed on low oil pressure.  The light is wired hot and the switch provides the ground when sufficient oil pressure is not available.  ……at least th…[Read more]

Checked internet.  Different sending unit for warning light.  So no more warning light since I have a gauge.

Good on ya Ric.

And a good question. I think the oil light has its own sending unit which is pretty much universal, and gauges have their own which have to match the gauge. But someone else might have the for-sure answer.

Installed remote oil filter and adapter for lines from old filter location.  After addressing several clearance issues, I finally got everything to clear exhaust and engine.  Used swivel 10AN fittings and aeroquip 5/8 hose.  Mounted new oil pressure sending unit.  MGTDR came with an oil warning light.  I don’t have the old engine anymore, but I…[Read more]

I’m back amonst the living again.  This is me.  Hi Randy.  Yes, i had email issue with gmail for a few months, yet I hope that is cleared up by now.  I’ve been getting gmail e-mail for a few months again.  I’m going to need a lot of help getting my London Roadster on the road again.

Good luck. Fingers crossed.

Once more into the breach!

So, after already running a 180* thermostat and being surprised by how hot she runs, i pulled the thermostat and gutted it. In lieu of eliminating it I left the large flange in place and was left with a one inch hole to maintain a small bit of restriction to the flow. Hoping this helps.

I can always go back in and…[Read more]
